Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space

Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space

  • Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
  • Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
  • Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
Détails sur le produit:
Lieu d'origine: Chine
Nom de marque: Dupont
Certification: CE
Numéro de modèle: Integratec ™ XP 51 IG (auparavant SFP-2860XP)
Documents: UF-IntegraTec-XP51-IG-en.pdf
Conditions de paiement et expédition:
Quantité de commande min: 1 pièce
Prix: Négociable
Détails d'emballage: Emballage standard d'exportation
Délai de livraison: 5- 8 jours de travail
Conditions de paiement: T/T
Capacité d'approvisionnement: 60000 unités par mois
Contact
Tous les produits
boîte de distribution d'éclairage (43)
boîte de distribution électrique (33)
Boîte de distribution imperméable (48)
Boîte de clôture de fibre de verre (60)
Commutateur automatique de transfert d'ATS (68)
Modules EDI (160)
Modules à membrane à ultrafiltration (76)
disjoncteur industriel (85)
système solaire de picovolte (72)
Station de charge électrique d'EV (21)
Relais modulaires de synchronisation (12)
Relais de contrôle d'automation (64)
Transformateur de régulateur de tension (16)
Ballons d'éclairage de film (144)
Lumière de ballon de lune (145)
Ballons du trépied LED (122)
Tour légère gonflable (76)
Accessoires de TB (6)
Description de produit détaillée
Mode de filtration XP 51 IG: Extérieur sous pression Type de membrane XP 51 IG: Fibre creuse
XP 51 IG Matériau de membrane: PVDF (fluorure de polyvinylidène) Taille des pores de membrane XP 51: Env. 0,03 µm
Processus de fonctionnement du module: Impasse Zone de membrane active XP 51 IG: 51 m²

DuPont XP 51 IG Ultrafiltration Membrane: High-Flux Industrial Water Filtration System
The DuPont XP 51 IG ultrafiltration membrane is designed for advanced separation in industrial water treatment. With its high-flux characteristics, this membrane achieves outstanding filtration performance while maintaining a precise molecular weight cut-off that effectively removes particles, bacteria, and macromolecules. Built to withstand demanding industrial conditions, it offers strong chemical resistance and a long operational life. The membrane's optimized configuration supports stable operation with low energy demand, making it well-suited for reverse osmosis pretreatment, wastewater reuse, and process water purification across a range of industrial sectors.
Product Specifications
Attribute Value
Brand Dupont™
Model XP 51 IG
Filtration Type Out-In Pressurized
Membrane Type Hollow fiber
Membrane Material PVDF (Polyvinylidene Fluoride)
Membrane Pore Size Approx. 0.03 µm
Module Operating Process Dead-end
Other Wetted Components Polyurethane, polyethylene, and polyamide
Active Membrane Area 51 m²
Shipping Weight 60 kg
Weight Empty 48 kg
Weight Filled 83 kg
Primary Application Wastewater treatment
Key Advantages
  • Municipal drinking water treatment
  • Industrial utility water processing
  • Industrial wastewater reuse
  • Municipal wastewater filtration
  • RO pretreatment solutions
Product Description
The DuPont IntegraTec XP 51 IG is an advanced ion exchange membrane engineered for high-efficiency chlor-alkali electrolysis, delivering superior performance in caustic soda (NaOH), chlorine (Cl₂), and hydrogen (H₂) production.
Designed with DuPont's proprietary IntegraTec technology, this membrane ensures exceptional current efficiency (≥96%) and low energy consumption, optimizing operational costs in membrane cell electrolyzers. Its reinforced perfluorinated polymer structure provides outstanding resistance to harsh chemical environments, including concentrated brine and high-temperature conditions.
The XP 51 IG features low gas permeability and stable voltage drop, ensuring consistent output and extended service life (typically >5 years). Ideal for modern electrolysis plants, it supports sustainable production with reduced power requirements and minimized caustic impurities.
Why Choose the XP 51 IG?
Smarter Filtration, Unmatched Purity
Proprietary pore structure technology ensures superior removal of pathogens, microplastics, and colloidal particles while preserving vital minerals for safer, cleaner water outcomes.
Ultra-High Efficiency
Engineered with DuPont's cutting-edge hydrophilic polymers, the XP 51 IG achieves up to 20% higher flux rates compared to conventional membranes, translating to faster processing and energy savings.
Built for Tough Conditions
Exceptional resistance to chlorine, pH extremes, and organic fouling ensures reliable operation in industrial wastewater, brackish water, or high-turbidity applications.
Sustainable by Design
Reduced fouling tendencies and easy-to-clean surfaces minimize chemical usage and downtime, supporting eco-conscious operations and lower lifecycle costs.
Plug-and-Play Compatibility
Seamlessly integrates into modular filtration systems, offering scalable solutions for both retrofits and new installations.
